Size-Chart
| Exter Thread | Inter Thread | ROD Size A/F | ROD Size A/C | Total Length | Thread Length | Thread Hole Depth | Small Hole |
|---|---|---|---|---|---|---|---|
| PG 07 | PG 07 | 14.00 | 15.50 | 15.00 | 5.00 | 9.00 | 10.00 |
| PG 09 | PG 09 | 17.00 | 18.90 | 16.50 | 6.00 | 9.50 | 12.50 |
| PG 11 | PG 11 | 20.00 | 22.00 | 17.00 | 6.00 | 10.00 | 15.00 |
| PG 13.5 | PG 13.5 | 22.00 | 24.40 | 19.00 | 6.50 | 11.50 | 17.00 |
| PG 16 | PG 16 | 24.00 | 26.70 | 20.00 | 6.50 | 12.50 | 18.50 |
| PG 21 | PG 21 | 30.00 | 33.00 | 22.00 | 7.00 | 13.50 | 24.00 |
| PG 29 | PG 29 | 39.00 | 42.50 | 24.50 | 8.00 | 15.00 | 32.00 |
| PG 36 | PG 36 | 50.00 | 54.00 | 28.50 | 9.00 | 17.50 | 42.00 |
| PG 42 | PG 42 | 57.00 | 61.00 | 32.00 | 10.00 | 20.00 | 48.00 |
| PG 48 | PG 48 | 64.00 | 69.00 | 33.00 | 10.00 | 21.00 | 52.50 |
| PG 07 | M 12 | 14.00 | 15.50 | 15.00 | 5.00 | 9.00 | 8.00 |
| PG 09 | M 12 | 17.00 | 18.90 | 16.50 | 6.00 | 9.50 | 8.00 |
| PG 09 | M 16 | 18.00 | 20.00 | 15.50 | 5.00 | 9.50 | 12.00 |
| PG 11 | M 16 | 20.00 | 22.00 | 17.00 | 6.00 | 10.00 | 12.00 |
| PG 11 | M 20 | 22.00 | 24.40 | 17.00 | 6.00 | 10.00 | 15.00 |
| PG 13 | M 20 | 22.00 | 24.40 | 18.50 | 6.00 | 11.50 | 15.00 |
| PG 16 | M 20 | 24.00 | 26.70 | 19.50 | 6.00 | 12.50 | 15.00 |
| PG 16 | M 25 | 27.00 | 29.50 | 20.50 | 7.00 | 12.50 | 18.50 |
| PG 21 | M 25 | 30.00 | 33.00 | 22.00 | 7.00 | 13.50 | 20.00 |
| PG 29 | M 32 | 39.00 | 42.50 | 24.50 | 8.00 | 15.00 | 27.00 |
| PG 29 | M 40 | 42.00 | 45.50 | 24.50 | 8.00 | 15.50 | 32.00 |
| PG 36 | M 40 | 50.00 | 54.00 | 27.50 | 8.00 | 17.50 | 35.00 |
| PG 36 | M 50 | 55.00 | 58.00 | 28.50 | 9.00 | 17.50 | 42.00 |
| PG 42 | M 50 | 57.00 | 60.00 | 31.00 | 9.00 | 20.00 | 44.00 |
| PG 48 | M 63 | 64.00 | 69.00 | 33.00 | 10.00 | 21.00 | 52.50 |
| M 12 | PG 07 | 14.00 | 15.50 | 15.00 | 5.00 | 9.00 | 8.00 |
| M 12 | PG 09 | 17.00 | 18.90 | 16.50 | 6.00 | 9.50 | 8.00 |
| M 16 | PG 09 | 18.00 | 20.00 | 15.50 | 5.00 | 9.50 | 12.00 |
| M 16 | PG 11 | 20.00 | 22.00 | 17.00 | 6.00 | 10.00 | 12.00 |
| M 20 | PG 11 | 22.00 | 24.40 | 17.00 | 6.00 | 10.00 | 15.00 |
| M 20 | PG 13.5 | 22.00 | 24.40 | 18.50 | 6.00 | 11.50 | 15.00 |
| M 20 | PG 16 | 24.00 | 26.70 | 19.50 | 6.00 | 12.50 | 15.00 |
| M 25 | PG 16 | 27.00 | 29.50 | 20.50 | 7.00 | 12.50 | 18.50 |
| M 25 | PG 21 | 30.00 | 33.00 | 22.00 | 7.00 | 13.50 | 20.00 |
| M 32 | PG 29 | 39.00 | 42.50 | 24.50 | 8.00 | 15.00 | 27.00 |
| M 40 | PG 29 | 42.00 | 45.50 | 24.50 | 8.00 | 15.50 | 32.00 |
| M 40 | PG 36 | 50.00 | 54.00 | 27.50 | 8.00 | 17.50 | 35.00 |
| M 50 | PG 36 | 55.00 | 58.00 | 28.50 | 9.00 | 17.50 | 42.00 |
| M 50 | PG 42 | 57.00 | 60.00 | 31.00 | 9.00 | 20.00 | 44.00 |
| M 63 | PG 48 | 64.00 | 69.00 | 33.00 | 10.00 | 21.00 | 52.50 |
| M 12 | M 12 | 14.00 | 15.50 | 15.00 | 5.00 | 9.00 | 8.00 |
| M 16 | M 16 | 18.00 | 20.00 | 15.50 | 5.00 | 9.50 | 12.00 |
| M 20 | M 20 | 22.00 | 24.40 | 18.50 | 6.00 | 11.50 | 15.00 |
| M 25 | M 25 | 27.00 | 29.50 | 21.50 | 7.00 | 13.50 | 20.00 |
| M 32 | M 32 | 34.00 | 37.00 | 24.50 | 8.00 | 8.00 | 27.00 |
| M 40 | M 40 | 42.00 | 45.50 | 26.00 | 8.00 | 16.50 | 35.00 |
| M 50 | M 50 | 55.00 | 58.00 | 28.50 | 9.00 | 17.50 | 42.00 |
| M 63 | M 63 | 64.00 | 69.00 | 33.00 | 10.00 | 21.00 | 52.50 |
